Yamaha EMX5014 Powered Mixing Console – Specifications & Details

The Yamaha EMX5014 is a 14-channel powered mixing console designed for live sound reinforcement, rehearsal spaces, houses of worship, and portable PA systems. It combines a full-featured analogue mixer, high-output power amplification, digital effects, and graphic EQ processing in a single chassis.

This unit is supplied with a dedicated flight case for transport and protection.

General

• Type: Powered analogue mixing console

• Total Channels: 14

• Mono Mic/Line Inputs: 6

• Stereo Line Inputs: 4 stereo channels (8 inputs total)

• Power Amplifier: Built-in dual power amplifier

• Included Accessories: Flight case

Inputs

• Mono Channels (1–6):

  • XLR mic input

  • 1/4" TRS line input

  • Global switchable phantom power

• Stereo Channels (7/8, 9/10, 11/12, 13/14):

  • 1/4" TRS line inputs

  • RCA inputs on selected channels

• Insert Points: Mono input channels

• Footswitch Input: Effects on/off control

Outputs

• Main Outputs:

  • Speakon speaker outputs

  • 1/4" line outputs

• Monitor Outputs:

  • Dedicated monitor out

• Auxiliary Sends:

  • Monitor send

  • Effects send

• Record Out:

  • RCA stereo output

• Headphone Output:

  • 1/4" stereo jack

Power Amplification

• Output Power:

  • 500W + 500W @ 4Ω

  • 350W + 350W @ 8Ω

• Amplifier Modes:

  • Stereo main

  • Main + monitor

  • Bridged mono

Equalisation & Processing

• Channel EQ (Mono Channels):

  • 3-band EQ

  • Sweepable mid frequency

• Channel EQ (Stereo Channels):

  • 2-band EQ

• Graphic EQ:

  • Dual 9-band graphic EQ

  • Assignable to main or monitor outputs

• High-Pass Filter: Mono channels

Effects

• Built-In Effects Processor: Yamaha SPX digital effects

• Effect Types:

  • Reverbs

  • Delays

  • Chorus and modulation effects

• Effect Control:

  • Dedicated effects return

  • Footswitch support

Metering & Controls

• LED output level meters

• Channel gain, EQ, pan, and level controls

• Master main and monitor level controls

Power & Construction

• Internal power supply

• Fan-cooled operation

• Metal chassis

• Supplied with protective flight case for transport and storage

Dimensions & Weight

• Width: approx. 444 mm

• Height: approx. 222 mm

• Depth: approx. 500 mm

• Weight: approx. 25 kg (mixer only)

Typical Applications

• Live sound reinforcement

• Rehearsal spaces

• Small to mid-sized venues

• Mobile PA systems

• Houses of worship and community events
