Offering all the features and specifications required from mixing consoles at this level, at a great price point. With features such as 3 band EQ, built-in channel compression, DSP effects and a hugely versatile MP3/USB/SD card playback and recording system.

Input channels, are fully featured with 3 band EQ, 2 Auxiliaries, balanced mic/line connectors, compressor control and a useful channel MUTE switch. Stereo channels differ only with 2 band EQ and no compressor.

Main outputs are balanced XLR, with additional jack outputs available for auxiliaries and control room, and RCA phono record/playback facilities.

The USB/SD card facility for stereo recording / playback make the CLUB XS ideal for project home recording or giving the ability to supply interval / backing music to your live performance. To add further practicality to the unit, there is a built in MP3 player and Bluetooth playback facility to give you every opportunity to make your live performance as quick and easy to set-up as possible.

Also included on both CLUB XS models is a high quality 16 programme DSP effects unit.

In addition to this, the CLUB XS models feature +48V phantom power on all mic channels, high quality 60mm smooth faders, and a robust quiet internal switchmode power supply.

• Inputs – 6
• Mic Input channels – 2
• Stereo Input channels – 2
• Gain – MIN – MAX
• Mic 6dB-+50dB
• Line +10dB – -34dB
• Frequency response
• Mic Channel – 10Hz – 20kHz+1/-3
• Channel EQ
• Hi – 12kHz
• Mid – 2.5kHz
• Lo – 45Hz
• Lo Cut – 80Hz
• MP3/USB/SD Audio playback – YES
• USB/SD Audio Recording -YES
• DSP Effects – YES
• Output Levels – MAX +25(BAL)
•   -MAX +20(UNBAL)
• Power requirement – 100V – 240V ~
• Dimensions(WxDxH) 227x359x70mm
